橡胶软接头,橡胶软连接有哪些结构种类

日期:2016-6-24 浏览量:675

  上海淞江减震器集团有限公司充分利用多年的设计、生产经验,对产品进行优化组合,力求品种齐全、质量稳定。所生产的产品包括:可曲挠橡胶接头、弹簧减震器、橡胶减震器、吊架减震器、不锈钢金属软管、波纹补偿器、减震台座等,产品销售面向全*各地,产品适用于各类水泵、风机、空调机组、发电机组、柴油机组、压缩机组、音响、冲床、动力试验台、消声室等基础减振以及各类管道、空调箱、风机盘管、轴流风机、风管等吊装减振。



  橡胶接头又可称为:可曲挠橡胶接头、橡胶软连接、软接头、柔性橡胶接头、橡胶膨胀节、避震喉、减震器等,是*高弹性、高气密性、耐介质和耐气候性的管道连接件。



  橡胶接头*般由内胶层、织物增强层(增强层有多层刮胶锦纶帘子布)、中胶层、外胶层、端部加固金属环或钢丝圈,经高温、高压硫化成型后,与金属法兰或平行接头松套组合而成的复合橡胶管。此产品利用了橡胶的高弹性、高气性、耐介质性、耐候性和耐辐射性等优点,可降低管道的振动及噪声,并可对因温度变化引起的热胀冷缩起补偿作用。

淞江橡胶接头整装待发

  根据介质不同所采用的橡胶材质也不同,有天然胶、丁苯胶、丁基胶、丁腈胶、三元乙丙胶、氯丁胶、硅橡胶、氟橡胶等等。分别具有耐热、耐酸、碱、耐腐蚀、耐磨、耐油等功能。



  上海淞江橡胶接头的基本分类:



  1.按使用性能分为通用、.种、耐热三大类。



  通用类:适用于输送温度为﹣15℃~80℃的水、浓度10%以下的酸溶液或碱溶液。



  .种类:适用于.殊性能的要求,如耐油、耐塞、耐臭氧、耐磨或耐化学腐蚀。



  耐热类:适用于输送温度高于80℃的水



  2.按结构形式分为单球体橡胶接头、双球体、三球体、弯头球体,,风压盘管体等。每种形式又可分同心等径、同心异径、偏心异径三类。



  3.按外形分为:



  同心同径、同心异径、偏心异径。



  3.按产品与管路的连接形式可分为法兰连接、螺纹连接和卡箍连接、螺纹管法兰连接等。



  4. 按工作压力分:



  0.25MPa、0.6MPa、1.0MPa、1.6MPa、2.5MPa、6.4MPa六个等*。



  上海淞江橡胶接头的性能及用途:



  1、体积小、重量轻、弹性好、安装维修方便。



  2、安装后可吸收管道震动产生的横向、轴向、角向位移;不受管道不同心,法兰不平行的限制。



  3、安装后可降低管道水泵等震动产生的噪音,吸振能力强。



  4、内无缝高压橡胶接头,在耐高温、耐酸碱、耐油的管道中更有效地防止了腐蚀性介质对橡胶接头内壁的侵蚀,提高了使用寿命。



  上海淞江橡胶接头的应用*域:



  本品由于可曲挠橡单球体胶接头具有良好的综合性能,所以它广泛用于化工、建筑、给水、排水、石油、轻重工业、冷冻、卫生、水暖、消防、电力等基础工程。根据材料不同可制成耐酸、耐碱、耐腐蚀、耐油、耐高温、耐辐射、耐磨、耐老化等各个品种,适应多种介质和环境。



  上海淞江减震器集团有限公司建立了*整套质量保证检测体系和严格的售后服务管理制度,公司为保证产品质量,严厉打击假冒伪劣产品,让客户买到安全合格放心的“淞江”品*产品。



  请新老客户购买产品时认准:



  1、产品标签说明:我公司出厂每件产品都有“淞江”品*,若无则为假冒我公司品*的产品,请及时与我公司联系,电话:021-66977771。



  2、产品合格证:我公司产品出厂时,所有产品必须经过严格的检验,检验合格才允许出厂,出厂产品持有我公司质检部出示的“产品合格证”。



  Rubber joint can be called: flexible rubber joints, rubber soft connection, flexible joint, flexible rubber joints, rubber expansion joint, shockproof throat, shock absorber, is a high elasticity, high gas tightness, medium resistance and resistant climate pipeline connecting piece.



  Rubber joints in general by the inner rubber layer and fabric reinforced layer (enhanced with a spectrum of squeegee nylon cord fabric layer) and layer and outer layer, end reinforced metal or the steel wire ring, after high temperature, high pressure vulcanization molding, and metal flange or parallel joints loose set of combination and compound rubber tube. This product uses the rubber of high elasticity, high gas, resistance, medium resistance, weather resistance and radiation resistance etc. advantages, reduce the vibration and noise of the pipeline, and the thermal expansion due to temperature change caused by the shrinkage compensation action.



  According to the different media used in the rubber material is also different, with natural rubber, styrene butadiene rubber, butyl rubber, nitrile rubber, ternary ethylene propylene rubber, chlorine butyl rubber, silicone rubber, fluorine rubber and so on. Respectively with heat, acid, alkali, corrosion resistance, wear resistance, oil resistance and other functions.



  The basic classification of Shanghai Songjiang Rubber joint:



  1 according to the use of performance is divided into general, special, heat three categories.



  General: suitable for conveying the temperature of ~80 DEG C 15 water, less than 10% of the concentration of acid or alkaline solutions.



  Special type: suitable for special performance requirements, such as oil, Naisai, ozone resistance, chemical corrosion or abrasion.



  Heat resistant: suitable for conveying water above 80



  2 according to the structure of the form is divided into single ball, double ball, three ball, elbow ball, and the wind pressure plate tube etc.. Each form can be divided into three categories, such as concentric, concentric, eccentric, eccentric, and so on.



  3 according to the outline:



  Concentric diameter, concentric different diameter, eccentric different diameter.



  3 according to the product and pipeline connection form can be divided into flange connection, threaded connection and clamp connection, threaded pipe flange connection and so on.



  4 according to work pressure:



  0.25MPa, 0.6MPa, 1.0MPa, 1.6MPa, 2.5MPa, 6.4MPa six levels.



  The properties and applications of Shanghai Songjiang Rubber joint:



  1, small size, light weight, good flexibility, easy installation and maintenance.



  2, after the installation of the pipeline vibration generated by the transverse, axial, angular displacement; not by the pipeline is not concentric, not parallel to the limit of the flange.



  3, after installation can reduce the noise caused by vibration of the pipeline pump, vibration absorption capacity.



  4, seamless high pressure rubber joints, in the high temperature, acid and alkali resistance, oil resistance of the pipeline more effectively prevent the corrosion of the media to the inner wall of the rubber erosion, improve the service life.



  Application of Shanghai Songjiang Rubber joint:



  This product due to flexure rubber spherical joint adhesive has good comprehensive performance, so it is widely used in chemical industry, construction, water supply, drainage, oil, light and heavy industry, refrigeration, sanitation, plumbing, fire, electricity and other infrastructure projects. According to the different materials can be made of acid, alkali, corrosion resistance, oil resistance, high temperature resistance, radiation resistance, resistance to abrasion, aging and other various species to adapt to a variety of media and the environment.
