Shanghai Songjiang shock absorber Group Co., Ltd. take full advantage of years of design, production experience, product of combinatorial optimization, strive to complete variety, quality and stability. The production of products include: flexible rubber joint, spring shock absorber, rubber shock absorber, hanger damper, stainless steel metal hose, bellows, vibration damping pedestal and, product sales for all over the country, the products are applicable to foundation vibration of various types of pumps, fan, air conditioning unit, motor, diesel unit, compression unit, audio, punching machine, dynamic test rig, anechoic chamber, and all kinds of pipe, air conditioning box, fan coil, axial flow fan, wind pipe hoisting vibration.
Commonly used rubber joints, also known as rubber joints, rubber joints, flexible rubber joints, high pressure rubber joints, etc.. Rubber joint of all the materials used are of high quality natural rubber, has good expansion compensation capability and vibration and noise reduction functions, installed in the pipe line can effectively alleviate the axial thrust of pipeline or is due to the thermal stress caused by the impact force of the telescopic displacement, and compared with the metal pipe compensator, rubber joint in use process can effectively reduce the noise pollution in pipeline construction area. This is the metalcompensator cannot achieve the.
General rubber joint is used as the main material of polyester cord fabric, the strength of connection material to ensure that rubber joint itself has enough bearing compressive capacity, makes the rubber joint can meet at this stage most of the pipe line construction, its products widely used in water, electricity, chemical, boating system, the main performance of resistance to high pressure, good elasticity, axial and transverse angle to the displacement) noise reduction, light weight, anti vibration, easy installation, flexible use, which is convenient for disassembly and maintenance, at the same time with acid and alkali resistance, oil. Commonly used rubber joints with different installation environment, the connection of threaded flange type of fractions, fixed flange and screw type 3;
1 screw connection joint rubber mounting screw rubber joint before installing the need to connect the two ends of the pipe in the horizontal plane flat, installation first rubber joint screw thread in which a tube and tube at the other end of the screw in, and always maintain in the horizontal plane, prevent the installation in the process of stress and tearing the rubber ball, then by hand or wrench to tighten the screw, finally to threaded joint rubber and at two ends of the pipe body is fixed on the not easy to stretch or distorted objects.
2 clamp connection rubber connector installation card hoop type rubber connector, hoops are adopted to replace flanges and bolts, installation can be the card hoop type rubber joint of two pipe were set in the side of pipeline, through the clamp fixing the rubber joint and the pipeline. When the clamp is connected with the rubber joint, the clamping hoop can be loosened. In order to compensate the pipeline due to thermal expansion and contraction, the purpose of water displacement generated by the. Compared with the general rubber joints, it has the following characteristics:
1, clamp rubber head, flange and bolt, save construction costs.
2, card type rubber head nozzle hoop without flanging, simplify the production process of rubber joints, saving raw materials.
3, the clamp type rubber joint simplifies the installation and maintenance work, improve the work efficiency.
4, the clamp is made of stainless steel, with corrosion resistance and other characteristics of the path from the DN50-400, the pressure level from 0.25mpa-1.0mpa.
Flange joint rubber mounting flange rubber joint before installing the need to connect the two ends of the pipe in the horizontal plane flat, installation to firmly fixed to one end of the pipe flat, then let the rubber joint flange rotation so that the flange holes surrounded by alignment, Sichuan screws, tighten the nut, then make flange level alignment on the other end flanged fittings with rubber joints, rubber rotary joint flange, flange around the mouth of the relative, Sichuan on the screw, the screw on the nut, the horizontal direction of the three closely connected, prevent the seal is not strict.
Shanghai Songjiang shock absorber Group Co., Ltd. established a set of quality guarantee detection system and strict after-sales service management system, the company is to ensure the quality of products, to crack down on fake and shoddy products, allows customers to buy the rest assured "Songjiang" brand products of safety inspection.
Please look for the new and old customers to buy products:
1, the product label instructions: our factory each product has "Song Jiang" brand, if not for the fake company brand products, please contact with our company, Tel: 021-66977771.
2, product certificate: our products factory, all products must undergo a rigorous inspection, inspection and acceptance before allowing the factory, the factory products to hold my company's quality inspection department to produce the product certificate".
